June 11, 2013

VCI-100 / Vestax Global site / Products / DJ Mixer

VCI-100 / Vestax Global site / Products / DJ Mixer

The link to the page in the hero image above gives a retrospective of one of the first Major Midi DJ controllers to take the controllerist market by storm. Before using the VCI-100SE from DJTechTools, I relied on a faderfox DJ1 in the early days and before that, the m-audio Oxygen8 midi keyboard controller was my first DJ controller when Traktor DJ Studio came onto the scene.

http://www.vestax.com/v/products/detail.php?cate_id=33







June 10, 2013

ZZ Top’s Billy Gibbons Remixes New Depeche Mode Single Soothe My Soul

This came outta nowhere.




April 25, 2013

Korg MS20 Mini Processed by Elektron Analog Four – YouTube

This is an impressive example of what just two synths can do.


April 10, 2013

MESSE13: Korg Volca Grooveboxes Video, Drums, B-line and analog poly – yes poly (Video) -Sonicstate.com

Coming This Summer!

MESSE13: Korg Volca Grooveboxes Video, Drums, B-line and analog poly -Sonicstate.com.

March 29, 2013

My First Sports Post.. Free Yankees Today!

Check out, my company, MLB, are giving away free access to the national Yankees Spring Training Game today @2:05 pm EST.




March 19, 2013

Slightly better way to Setup Mixlr with Traktor and Z2 Mixer

mixlr

If your like me (and maybe you are if you are here) and have to try out all the latest and greatest audio/dj related web apps, then you may have tried Mixlr which allows you to do live audio streaming online either on their website or  have loaded up their iOS or Android App.

On the Broadcasting side, you need to run Mixlr’s Broadcaster App and configure it with your software setup. In my case, I of course use Native Instruments’ Traktor App.  I also recently purchased Native Instrumens Z2 mixer which is awesome in its own right (yea, i know, fanboy) working seamlessly with Traktor doubling as the Sound Card / Audio Interface.

Mixlr’s Directions speak to using Cycling 74′s SoundFlower App to internally ‘wire’ Traktor’s Outputs virtually into Mixlr. This is fine, but the way they describe it is a bit more complicated than it needs to be I think.

1. On a mac, open up Audio Midi Settings Application.

2. Create a new Aggregate Device with Soundflower 2 (or Soundflower 16 channels if you want, you only to use 2), along with the Z2 Device or whichever physical audio interface you have. On the Z2 Mixer, Sample Rate is set to fixed @ 48khz. Then, select the Soundflower Device in Audio Midi App and make sure the SoundFlower device is set to 44.1khz Sample Rate! (Mixlr needs Clock set to 44.1khz or you will have the incorrect pitch in your audio)

1-ClockSourceSoundFlowerSelected A. My Mixlr Aggregate Device Settings. Checked Soundflower (2 ch) and my Z2 Mixer. Named Device Mixlr
2-AudoMIDISettings1 B. My Mixlr Aggregate Device Settings Order (make sure SoundFlower is listed first, then your sound card)
3-Z248k C. See that the Z2 is set to 48khz Sampling Rate.
4-Soundflower2chanel44.1k D. My SoundFlower 2 Channel Settings (44.1 khz)

3. Inside of Traktor’s audio settings, select your Aggregate Audio device (I had named mine ‘Mixlr’)

5-TraktorSettingsAudioSetup Select Mixlr as Audio Device and select 44.1 khz for Sample Rate

4. For Monitor Settings, you need to point to the Aggregate Device  Channels where the Z2 is, so in our case, it comes on channels 4 and 5.

5. For Master Output Settings, keep the usual Z2 settings (outs 3 and 4)

6. Then.. on the RECORD Output channel Selection, this is where you should select Output to Mixlr Channels 1 and 2, which is the 2 Soundflower Channels. This is the Simple Setting workaround I found.

6-TraktorOutputRouting Route your audio. Key is Output record set to 0 and 1.

7. You can check that the Mixer Recorder option inside of the Traktor Preferences is still set to Internal. You can still record internally, as well as broadcast out to Mixlr for higher fidelity capture of your set.

8. Exit out of Traktor Settings

9. In the Mixlr Broadcast App, just change audio settings and select Mixlr Channels 1 and 2 as the input and make sure you are running some audio through Traktor Software and the Master level is up a bit. Mixlr App should recognize the internal Audio and you should save the settings and be good to go. No need to set a Monitor output setting in Mixlr.

I like that this keeps the signal path digital the entire time and no extra fiddling with cables going out of a mixer and into a spare stereo channel on your sound card to capture the audio for Mixlr. You should be up and running a bit faster and be happy Mixlr’ing.
